PFL540 LED

Back
Family Spec Sheet
PFL230 PFL230 410 mm 410 mm 250 mm 250 mm
PFL240 PFL240 560 mm 560 mm 330 mm 330 mm
PFL540 PFL540 867 mm 867 mm 330 mm 330 mm

IP66. Class I. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. RFC® Reflection Free Contour main lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. The luminaire is factory-sealed, factory-wired and supplied with 33’ of black, three conductor, flexible SEOW cord for power connection at pole-base hand hole.
Recommended mounting height 12-40 ft, depending on lamp type selected. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK08
SchutzartIP66
AbdeckungPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Korrosionsschutz5CE
BefestigungLuminaire mounts directly to pole top tenon. No bracket required for single luminaire configuration. See mounting accessories for other mounting bracket options.

Elektrik

LED TreiberIntegral EC electronic converter
Kabel30 feet of flexible 18/5 cable
Leistungsfaktor> 0.9
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIn-line bracket 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

CRI

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
108-0822[S70] Type II ShortLED-48/96W / 700 mA - 4000 K13171.580electronic gear33.07
108-0823[S70] Type II ShortLED-36/72W / 700 mA - 4000 K9878.680electronic gear30.86
108-0824[S70] Type II ShortLED-24/48W / 700 mA - 4000 K6585.880electronic gear28.66
108-0825[S70] Type II ShortLED-24/72W / 1050 mA - 4000 K9478.280electronic gear28.66
108-0826[S70] Type II ShortLED-36/108W / 1050 mA - 4000 K14217.380electronic gear30.86
108-0827[S70] Type II ShortLED-48/144W / 1050 mA - 4000 K18956.480electronic gear33.07
108-0828[S65] Type III MediumLED-24/48W / 700 mA - 4000 K6763.780electronic gear30.86
108-0829[S65] Type III MediumLED-24/72W / 1050 mA - 4000 K9816.680electronic gear28.66
108-0830[S65] Type III MediumLED-36/72W / 700 mA - 4000 K10145.680electronic gear30.86
108-0831[S65] Type III MediumLED-36/108W / 1050 mA - 4000 K1472580electronic gear30.86
108-0832[S65] Type III MediumLED-48/96W / 700 mA - 4000 K13527.480electronic gear33.07
108-0833[S65] Type III MediumLED-48/144W / 1050 mA - 4000 K19633.380electronic gear33.07
108-0949[S60] Type III ShortLED-24/48W / 700 mA - 4000 K670180electronic gear28.66
108-0950[S60] Type III ShortLED-36/72W / 700 mA - 4000 K10051.680electronic gear30.86
108-0951[S60] Type III ShortLED-48/96W / 700 mA - 4000 K13402.180electronic gear33.07
108-0952[S60] Type III ShortLED-24/72W / 1050 mA - 4000 K9628.280electronic gear28.66
108-0953[S60] Type III ShortLED-36/108W / 1050 mA - 4000 K14442.380electronic gear30.86
108-0954[S60] Type III ShortLED-48/144W / 1050 mA - 4000 K19256.480electronic gear33.07
108-0955[R65] Type IV MediumLED-24/48W / 700 mA - 4000 K6295.780electronic gear28.66
108-0956[R65] Type IV MediumLED-36/72W / 700 mA - 4000 K9443.580electronic gear30.86
108-0957[R65] Type IV MediumLED-48/96W / 700 mA - 4000 K12591.380electronic gear33.07
108-0958[R65] Type IV MediumLED-24/72W / 1050 mA - 4000 K9104.580electronic gear28.66
108-0959[R65] Type IV MediumLED-36/108W / 1050 mA - 4000 K13656.780electronic gear30.86
108-0960[R65] Type IV MediumLED-48/144W / 1050 mA - 4000 K1820980electronic gear33.07
108-0961[A60] Type IV Very ShortLED-24/48W / 700 mA - 4000 K6145.680electronic gear28.66
Showing 1 to 25 of 112 Entries
