ASP500 series

ASP530 LED

Static White

Choose a family:

H340 ⌀560 mm | ASP530 LED

Home

Products

Pole-Mounted Luminaires

ASP530 LED

Family Spec Sheet Installation Instructions More Downloads

IP66. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone rubber gaskets. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Optional 2200 K version available. To be specified at time of ordering.

Colours

RAL9004 Signal black

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone rubber gasket
Impact Protection	IK10
Ingress Protection	IP66
Finish	Powdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection	5CE
Mounting	Recommended mounting height 3.0-4.5 m, depending on lamp type selected. Brackets to be ordered separately.

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	30 feet of flexible 18/5 cable
Power Factor	< 0.9

Additional Information

BUG Rating

Please see individual Spec Sheets for classification of Backlight, Uplight and Glare

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
127-8253	asymmetric, side throw [S60]	LED-12/24W / 700 mA - 4000 K	3187.9	80
127-8254	asymmetric, side throw [S60]	LED-12/24W / 700 mA - 3000 K	2982.2	80
127-8255	asymmetric, side throw [S60]	LED-24/48W / 700 mA - 4000 K	6375.7	80
127-8256	asymmetric, side throw [S60]	LED-24/48W / 700 mA - 3000 K	5964.4	80
127-8257	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 4000 K	9563.6	80
127-8258	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 3000 K	8946.6	80
127-8301	asymmetric, side throw [S70]	LED-12/24W / 700 mA - 4000 K	3146.8	80
127-8302	asymmetric, side throw [S70]	LED-12/24W / 700 mA - 3000 K	2943.8	80
127-8303	asymmetric, side throw [S70]	LED-24/48W / 700 mA - 4000 K	6293.7	80
127-8304	asymmetric, side throw [S70]	LED-24/48W / 700 mA - 3000 K	5887.6	80
127-8305	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 4000 K	9440.5	80
127-8306	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 3000 K	8831.4	80
127-8307	asymmetric, forward throw [A60]	LED-12/24W / 700 mA - 4000 K	3060	80
127-8308	asymmetric, forward throw [A60]	LED-12/24W / 700 mA - 3000 K	2862.6	80
127-8309	asymmetric, forward throw [A60]	LED-24/48W / 700 mA - 4000 K	6120	80
127-8310	asymmetric, forward throw [A60]	LED-24/48W / 700 mA - 3000 K	5725.2	80
127-8311	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 4000 K	9180.1	80
127-8312	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 3000 K	8587.8	80
127-8313	asymmetric, side throw [S65]	LED-12/24W / 700 mA - 4000 K	3257	80
127-8314	asymmetric, side throw [S65]	LED-12/24W / 700 mA - 3000 K	3046.9	80
127-8315	asymmetric, side throw [S65]	LED-24/48W / 700 mA - 4000 K	6514	80
127-8316	asymmetric, side throw [S65]	LED-24/48W / 700 mA - 3000 K	6093.8	80
127-8317	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 4000 K	9771.1	80
127-8318	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 3000 K	9140.7	80
127-8319	rectangular, side throw [R65]	LED-12/24W / 700 mA - 4000 K	2980.8	80
127-8320	rectangular, side throw [R65]	LED-12/24W / 700 mA - 3000 K	2788.5	80
127-8321	rectangular, side throw [R65]	LED-24/48W / 700 mA - 4000 K	5961.7	80
127-8322	rectangular, side throw [R65]	LED-24/48W / 700 mA - 3000 K	5577	80
127-8323	rectangular, side throw [R65]	LED-36/72W / 700 mA - 4000 K	8942.5	80
127-8324	rectangular, side throw [R65]	LED-36/72W / 700 mA - 3000 K	8365.5	80
127-8360	pedestrian/bicycle lane [P65]	LED-12/24W / 700 mA - 3000 K	2916.3	80
127-8361	pedestrian/bicycle lane [P65]	LED-12/24W / 700 mA - 4000 K	3117.5	80
127-8362	pedestrian/bicycle lane [P65]	LED-24/48W / 700 mA - 3000 K	5832.7	80
127-8363	pedestrian/bicycle lane [P65]	LED-24/48W / 700 mA - 4000 K	6234.9	80
127-8364	pedestrian/bicycle lane [P65]	LED-36/72W / 700 mA - 3000 K	8749	80
127-8365	pedestrian/bicycle lane [P65]	LED-36/72W / 700 mA - 4000 K	9352.4	80

Showing 1 to 36 of 36 entries.

Accessories

Mounting Accessories

Control

Optical Accessories

Part-ID	Title	Specifications
		Text	PDF
300-9162	Wall bracket BA0-420, single
300-9163	Pole bracket BA1-420, single
300-9164	Pole bracket BA2-420, double
300-9165	Pole bracket BA3-420, triple
