SBI100 series

SBI120 LED

Static White

Choose a family:

L225×W140 mm | SBI120 LED L250×W160 mm | SBI130 LED
Home
Products
Ceiling Luminaires
SBI120 LED
Family Spec Sheet Installation Instructions More Downloads

IP66. Class I. IK06. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept.

SBI120 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK06
Ingress ProtectionIP66
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
CableTwo cable entries
Additional Information

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
138-8996symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1347.180
138-8997symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1610.780
138-8998symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K144080
138-8999symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1721.880
138-9002symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1511.880
138-9003symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1496.580
138-9005symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1616.180
138-9006symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1599.780
138-6000symmetric, wide beam [B]LED-6/18W / 1050 mA - 3000 K2018.880
138-6003symmetric, wide beam [B]LED-6/18W / 1050 mA - 4000 K2112.780
138-6001symmetric, medium beam [M]LED-6/18W / 1050 mA - 3000 K2167.280
138-6004symmetric, medium beam [M]LED-6/18W / 1050 mA - 4000 K226880
138-6002symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 3000 K2165.680
138-6005symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 4000 K2266.480
Showing 1 to 14 of 14 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
430-0013DALI interface
ItemDownload
Product Images
Photometrics
Installation Instructions
