PTY400 Serie
PTY414 LED
IP66/IP67. Class I. IK10. Marine-grade, all-aluminium construction. Pole section features galvanised steel reinforcement core. 5CE superior corrosion protection including PCS hardware. RFC™ Reflection Free Contour main lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control.
Farben
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Materialinformationen
| Gehäuse | Marine-grade, all-aluminium construction. Pole section features galvanised steel reinforcement core |
| Schrauben | PCS |
| Dichtung | Silicone CCG® Controlled Compression Gasket |
| Schlagfestigkeit | IK10 |
| Schutzart | IP66/IP67 |
| Korrosionsbeständigkeit | 5CE |
| Installation | Luminaire is factory-sealed and does not need to be opened during installation |
Elektrische Informationen
| Netzgerät / Vorschaltgerät | Integral EC electronic converter |
| Überspannungsschutz | 6/6 kV (SP10 optional) |
Weitere Informationen
| Lifetime | Ta=25° L90B10 > 90000h |
| BUG Rating | Please see individual Spec Sheets for classification of Backlight, Uplight and Glare |
- - - -
Accessories
| Item | Download |
|---|---|
| Produktbilder | |
| Photometrie | |
| Installationsanleitung |
