VLS410 LED

Back
Family Spec Sheet
170 mm 170 mm 255 mm 255 mm
210 mm 210 mm 260 mm 260 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseLuminaire body and lens frame constructed in die cast aluminum.
SchraubenPCS polymer coated stainless steel
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK08
SchutzartIP66
AbdeckungPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Korrosionsschutz5CE
BefestigungSuitable for installation over a standard 4” recessed junction box.

Elektrik

LED TreiberIntegral EC electronic converter
KabelTwo cable entries
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
131-9503symmetric, medium beam [M]LED-3/6W / 700 mA - 3000 K586.580electronic gear7.20
131-9507symmetric, medium beam [M]LED-3/6W / 700 mA - 4000 K626.980electronic gear7.20
131-9504symmetric, narrow beam [N]LED-3/6W / 700 mA - 3000 K656.980electronic gear7.20
131-9508symmetric, narrow beam [N]LED-3/6W / 700 mA - 4000 K702.280electronic gear7.20
131-9502asymmetric, forward throw [A60]LED-3/6W / 700 mA - 3000 K260.680electronic gear7.20
131-9506asymmetric, forward throw [A60]LED-3/6W / 700 mA - 4000 K278.580electronic gear7.20
131-9512symmetric, narrow beam up and forward-throw down [N/A60]LED-2x3/12W / 700 mA - 3000K981.180electronic gear7.20
131-9518symmetric, narrow beam up and forward-throw down [N/A60]LED-2x3/12W / 700 mA - 4000K917.880electronic gear7.20
131-9513symmetric, medium beam up and down [M/M]LED-2x3/12W / 700 mA - 3000K1173.180electronic gear7.20
131-9519symmetric, medium beam up and down [M/M]LED-2x3/12W / 700 mA - 4000K125480electronic gear7.20
131-9514symmetric, narrow beam up and medium beam down [N/M]LED-2x3/12W / 700 mA - 3000K1243.780electronic gear7.20
131-9520symmetric, narrow beam up and medium beam down [N/M]LED-2x3/12W / 700 mA - 4000K1329.480electronic gear7.20
131-9515symmetric, narrow beam up and down [N/N]LED-2x3/12W / 700 mA - 3000K1314.280electronic gear7.20
131-9521symmetric, narrow beam up and down [N/N]LED-2x3/12W / 700 mA - 4000K1404.880electronic gear7.20
131-0198symmetric, medium beam [M]LED-3/9W / 1050mA - 3000 K869.680electronic gear7.70
131-0199symmetric, medium beam [M]LED-3/9W / 1050mA - 4000 K91080electronic gear7.70
131-0200symmetric, narrow beam [N]LED-3/9W / 1050mA - 3000 K97480electronic gear7.70
131-0201symmetric, narrow beam [N]LED-3/9W / 1050mA - 4000 K1019.380electronic gear7.70
131-0202asymmetric, forward throw [A60]LED-3/9W / 1050mA - 3000 K386.480electronic gear7.70
131-0203asymmetric, forward throw [A60]LED-3/9W / 1050mA - 4000 K404.380electronic gear7.70
131-9830symmetric, medium beam up and forward throw down [M/A60]LED-2x3/18W / 1050mA - 3000 K1256.280electronic gear7.70
131-9835symmetric, medium beam up and forward throw down [M/A60]LED-2x3/18W / 1050mA - 4000 K1314.780electronic gear7.20
131-9836symmetric, narrow beam up and forward-throw down [N/A60]LED-2x3/18W / 1050mA - 4000 K1424.180electronic gear7.20
131-9831symmetric, narrow beam up and forward-throw down [N/A60]LED-2x3/18W / 1050mA - 3000 K1360.880electronic gear7.70
131-9832symmetric, medium beam up and down [M/M]LED-2x3/18W / 1050mA - 3000 K1739.580electronic gear7.70
Showing 1 to 25 of 70 Entries
