SLS400 series

SLS420 LED

Static White

Choose a family:

H10.04"×D6.69" | SLS410 LED H10.24"×D8.66" | SLS420 LED

Home

Products

Surface-Mounted Wall Luminaires

SLS420 LED

Family Spec Sheet Installation Instructions More Downloads

Surface-mounted wall luminaire. IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Suitable for Up, Down, or Up/Down light distribution. Suitable for installation over 4” recessed junction box. Emergency Lighting Package option available; to be specified as accessory with order. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1) For DarkSky compliant configurations of this product, please find the spec sheet and DarkSky certificate in the library.

Colours

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

RAL8019 Dark Bronze

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone rubber gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish	Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection	5CE

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Two cable entries
Power Supply	Integral [ECG] electronic 0-10 V dimmable driver in 120-277 universal voltage.

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h
BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
131-9533	symmetric, medium beam [M]	LED-6/12W / 700 mA - 3000 K	1172.9	80
131-9537	symmetric, medium beam [M]	LED-6/12W / 700 mA - 4000 K	1253.8	80
131-9534	symmetric, narrow beam [N]	LED-6/12W / 700 mA - 3000 K	1313.8	80
131-9538	symmetric, narrow beam [N]	LED-6/12W / 700 mA - 4000 K	1404.4	80
131-9532	asymmetric, forward throw [A60]	LED-6/12W / 700 mA - 3000 K	852.9	80
131-9536	asymmetric, forward throw [A60]	LED-6/12W / 700 mA - 4000 K	911.7	80
131-9542	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/24W / 700 mA - 3000 K	2167.2	80
131-9548	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/24W / 700 mA - 4000 K	2316.6	80
131-9543	symmetric, medium beam up and down [M/M]	LED-2x6/24W / 700 mA - 3000 K	2346.2	80
131-9549	symmetric, medium beam up and down [M/M]	LED-2x6/24W / 700 mA - 4000 K	2508.1	80
131-9544	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/24W / 700 mA - 3000 K	2487.3	80
131-9550	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/24W / 700 mA - 4000 K	2658.8	80
131-9545	symmetric, narrow beam up and down [N/N]	LED-2x6/24W / 700 mA - 3000 K	2628.4	80
131-9551	symmetric, narrow beam up and down [N/N]	LED-2x6/24W / 700 mA - 4000 K	2809.6	80
131-0234	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 3000 K	1739.1	80
131-0235	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 4000 K	1820	80
131-0236	symmetric, narrow beam [N]	LED-6/18W / 1050 mA - 3000 K	1948	80
131-0237	symmetric, narrow beam [N]	LED-6/18W / 1050 mA - 4000 K	2038.6	80
131-0238	asymmetric, forward throw [A60]	LED-6/18W / 1050 mA - 3000 K	1264.6	80
131-0239	asymmetric, forward throw [A60]	LED-6/18W / 1050 mA - 4000 K	1323.4	80
131-9800	symmetric, medium beam up and down [M/M]	LED-2x6/36W / 1050 mA - 3000 K	3478.9	80
131-9805	symmetric, medium beam up and down [M/M]	LED-2x6/36W / 1050 mA - 4000 K	3640.7	80
131-9801	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/36W / 1050 mA - 3000 K	3688.1	80
131-9806	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/36W / 1050 mA - 4000 K	3859.6	80
131-9802	symmetric, narrow beam up and down [N/N]	LED-2x6/36W / 1050 mA - 3000 K	3897.2	80
131-9807	symmetric, narrow beam up and down [N/N]	LED-2x6/36W / 1050 mA - 4000 K	4078.5	80
131-9798	symmetric, medium beam up and forward throw down [M/A60]	LED-2x6/36W / 1050 mA - 3000 K	3004.2	80
131-9803	symmetric, medium beam up and forward throw down [M/A60]	LED-2x6/36W / 1050 mA - 4000 K	3144	80
131-9799	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/36W / 1050 mA - 3000 K	3213.4	80
131-9804	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/36W / 1050 mA - 4000 K	3362.8	80
131-0240	symmetric, medium beam [M]	LED-6/26W / 1400 mA - 3000 K	2224.5	80
131-0241	symmetric, medium beam [M]	LED-6/26W / 1400 mA - 4000 K	2325.6	80
131-0242	symmetric, narrow beam [N]	LED-6/26W / 1400 mA - 3000 K	2491.7	80
131-0243	symmetric, narrow beam [N]	LED-6/26W / 1400 mA - 4000 K	2604.9	80
131-0244	asymmetric, forward throw [A60]	LED-6/26W / 1400 mA - 3000 K	1617.5	80
131-0245	asymmetric, forward throw [A60]	LED-6/26W / 1400 mA - 4000 K	1691	80
131-9810	symmetric, medium beam up and down [M/M]	LED-2x6/52W / 1400mA - 3000 K	4449.8	80
131-9815	symmetric, medium beam up and down [M/M]	LED-2x6/52W / 1400mA - 4000 K	4652	80
131-9811	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/52W / 1400mA - 3000 K	4717.3	80
131-9816	symmetric, narrow beam up and medium beam down [N/M]	LED-2x6/52W / 1400mA - 4000 K	4931.7	80
131-9812	symmetric, narrow beam up and down [N/N]	LED-2x6/52W / 1400mA - 3000 K	4984.8	80
131-9817	symmetric, narrow beam up and down [N/N]	LED-2x6/52W / 1400mA - 4000 K	5211.4	80
131-9808	symmetric, medium beam up and forward throw down [M/A60]	LED-2x6/52W / 1400mA - 3000 K	3842.6	80
131-9813	symmetric, medium beam up and forward throw down [M/A60]	LED-2x6/52W / 1400mA - 4000 K	4017.3	80
131-9809	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/52W / 1400mA - 3000 K	4110.1	80
131-9814	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x6/52W / 1400mA - 4000 K	4297	80
131-9311	symmetric, medium beam [M]	LED-6/12W / 700 mA - 2700 K	1092	80
131-9257	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 2700 K	1658.3	80
131-9266	symmetric, medium beam [M]	LED-6/26W / 1400 mA - 2700 K	2103.2	80
131-9315	symmetric, medium beam up and down [M/M]	LED-2x6/24W / 700 mA - 2700 K	2184.4	80

Showing 1 to 50 of 70 entries.

Accessories

Electrical Accessories

Control

Mounting Accessories

Part-ID	Title	Specifications
		Text	PDF
131-6900	_LS420/430 LED Emergency Lighting Package
