SLS410 LED

Surface-mounted wall luminaire. IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Suitable for Up, Down, or Up/Down light distribution. Supplied with wall plate to fit over 4” recessed junction box. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Material

Body: Marine-grade, die-cast aluminium alloy

Fasteners: PCS hardware

Gasket: Silicone rubber gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish: Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.

Corrosion Protection: 5CE

Mounting:

Electrical

Ballast / Driver: Integral EC electronic converter

Cable: Two cable entries

Power Factor:

Power Supply: Integral [ECG] electronic 0-10 V dimmable driver in 120-277 universal voltage.

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

BUG Rating: Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

To

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
131-9473	symmetric, medium beam [M]	LED-3/6W / 700 mA - 3000 K	586.5	80
131-9477	symmetric, medium beam [M]	LED-3/6W / 700 mA - 4000 K	626.9	80
131-9483	symmetric, medium beam up and down [M/M]	LED-2x3/12W / 700 mA - 3000K	1173.1	80
131-9489	symmetric, medium beam up and down [M/M]	LED-2x3/12W / 700 mA - 4000K	1254	80
131-9472	asymmetric, forward throw [A60]	LED-3/6W / 700 mA - 3000 K	260.6	80
131-9476	asymmetric, forward throw [A60]	LED-3/6W / 700 mA - 4000 K	278.5	80
131-9484	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/12W / 700 mA - 3000K	1243.7	80
131-9490	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/12W / 700 mA - 4000K	1329.4	80
131-9474	symmetric, narrow beam [N]	LED-3/6W / 700 mA - 3000 K	656.9	80
131-9478	symmetric, narrow beam [N]	LED-3/6W / 700 mA - 4000 K	702.2	80
131-9482	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x3/12W / 700 mA - 3000K	917.8	80
131-9488	symmetric, narrow beam up and forward-throw down [N/A60]	LED-2x3/12W / 700 mA - 4000K	981.1	80
131-9485	symmetric, narrow beam up and down [N/N]	LED-2x3/12W / 700 mA - 3000K	1314.2	80
131-9491	symmetric, narrow beam up and down [N/N]	LED-2x3/12W / 700 mA - 4000K	1404.8	80
131-0222	symmetric, medium beam [M]	LED-3/9W / 1050mA - 3000 K	869.6	80
131-0223	symmetric, medium beam [M]	LED-3/9W / 1050mA - 4000 K	910	80
131-0224	symmetric, narrow beam [N]	LED-3/9W / 1050mA - 3000 K	974	80
131-0225	symmetric, narrow beam [N]	LED-3/9W / 1050mA - 4000 K	1019.3	80
131-0226	asymmetric, forward throw [A60]	LED-3/9W / 1050mA - 3000 K	386.4	80
131-0227	asymmetric, forward throw [A60]	LED-3/9W / 1050mA - 4000 K	404.3	80
131-9864	symmetric, medium beam up and down [M/M]	LED-2x3/18W / 1050mA - 3000 K	1739.5	80
131-9869	symmetric, medium beam up and down [M/M]	LED-2x3/18W / 1050mA - 4000 K	1820.4	80
131-9865	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/18W / 1050mA - 3000 K	1844	80
131-9870	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/18W / 1050mA - 4000 K	1929.8	80
131-9866	symmetric, narrow beam up and down [N/N]	LED-2x3/18W / 1050mA - 3000 K	1948.6	80

Showing 1 to 25 of 70 Entries
