QLS410 LED

IP66, Class I. IK07. Surface mounted LED wall luminaire. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Integral driver. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming on request. Suitable for installation over 4" recessed junction box. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering. ADA (American Disabilities Act) Compliant.

Colours

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

RAL8019 Dark Bronze

Material

Body	Luminaire body and lens frame constructed in die cast aluminum.
Fasteners	PCS polymer coated stainless steel
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish	Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection	5CE
Mounting	Suitable for installation over a standard 4” recessed junction box.

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Two cable entries
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h
BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

To

Wattage

To

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
131-9401	symmetric, medium beam [M]	LED-3/6W / 700 mA - 3000 K	586.5	80
131-9404	symmetric, medium beam [M]	LED-3/6W / 700 mA - 4000 K	626.9	80
131-9409	symmetric, medium beam up and down [M/M]	LED-2x3/12W / 700 mA - 3000K	1173.1	80
131-9414	symmetric, medium beam up and down [M/M]	LED-2x3/12W / 700 mA - 4000K	1254	80
131-9400	asymmetric, side throw beam [S]	LED-3/6W / 700 mA - 3000 K	553.8	80
131-9403	asymmetric, side throw beam [S]	LED-3/6W / 700 mA - 4000 K	592	80
131-9407	symmetric, medium beam up and side throw down [M/S]	LED-2x3/12W / 700 mA - 3000K	1140.3	80
131-9408	symmetric, narrow beam up and side-throw down [N/S]	LED-2x3/12W / 700 mA - 3000K	1210.8	80
131-9412	symmetric, medium beam up and side throw down [M/S]	LED-2x3/12W / 700 mA - 4000K	1218.9	80
131-9413	symmetric, narrow beam up and side-throw down [N/S]	LED-2x3/12W / 700 mA - 4000K	1294.3	80
131-9420	symmetric, narrow beam [N]	LED-3/6W / 700 mA - 3000 K	656.9	80
131-9421	symmetric, narrow beam [N]	LED-3/6W / 700 mA - 4000 K	702.2	80
131-9416	symmetric, narrow beam up and down [N/N]	LED-2x3/12W / 700 mA - 3000K	1314.2	80
131-9417	symmetric, narrow beam up and down [N/N]	LED-2x3/12W / 700 mA - 4000K	1404.8	80
131-9422	rectangular asymmetric Type II [R45]	LED-3/6W / 700 mA - 3000 K	592.2	80
131-9424	rectangular asymmetric Type II [R45]	LED-3/6W / 700 mA - 4000 K	633	80
131-9423	medium beam up and forward throw down [M/R45]	LED-2x3/12W / 700 mA - 3000K	1178.8	80
131-9425	medium beam up and forward throw down [M/R45]	LED-2x3/12W / 700 mA - 4000K	1260.1	80
131-9462	symmetric narrow beam up and forward throw down [E/R45]	LED-2x3/12W / 700 mA - 3000K	1249.4	80
131-9463	symmetric narrow beam up and forward throw down [E/R45]	LED-2x3/12W / 700 mA - 4000K	1335.5	80
131-0174	symmetric, medium beam [M]	LED-3/9W / 1050mA - 3000 K	869.6	80
131-0175	symmetric, medium beam [M]	LED-3/9W / 1050mA - 4000 K	910	80
131-0176	symmetric, narrow beam [N]	LED-3/9W / 1050mA - 3000 K	974	80
131-0177	symmetric, narrow beam [N]	LED-3/9W / 1050mA - 4000 K	1019.3	80
131-0178	rectangular asymmetric Type II [R45]	LED-3/9W / 1050mA - 3000 K	878.1	80
131-0179	rectangular asymmetric Type II [R45]	LED-3/9W / 1050mA - 4000 K	918.9	80
131-9724	symmetric, medium beam up and down [M/M]	LED-2x3/18W / 1050mA - 3000 K	1739.5	80
131-9729	symmetric, medium beam up and down [M/M]	LED-2x3/18W / 1050mA - 4000 K	1820.4	80
131-9726	symmetric, narrow beam up and down [N/N]	LED-2x3/18W / 1050mA - 3000 K	1948.6	80
131-9731	symmetric, narrow beam up and down [N/N]	LED-2x3/18W / 1050mA - 4000 K	2039.3	80
131-9725	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/18W / 1050mA - 3000 K	1844	80
131-9730	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/18W / 1050mA - 4000 K	1929.8	80
131-9722	medium beam up and forward throw down [M/R45]	LED-2x3/18W / 1050mA - 3000 K	1747.9	80
131-9727	medium beam up and forward throw down [M/R45]	LED-2x3/18W / 1050mA - 4000 K	1829.2	80
131-9723	symmetric narrow beam up and forward throw down [E/R45]	LED-2x3/18W / 1050mA - 3000 K	1852.5	80
131-9728	symmetric narrow beam up and forward throw down [E/R45]	LED-2x3/18W / 1050mA - 4000 K	1938.7	80
131-0180	symmetric, medium beam [M]	LED-3/13W / 1400 mA - 3000 K	1112.2	80
131-0181	symmetric, medium beam [M]	LED-3/13W / 1400 mA - 4000 K	1162.8	80
131-0182	symmetric, narrow beam [N]	LED-3/13W / 1400 mA - 3000 K	1245.8	80
131-0183	symmetric, narrow beam [N]	LED-3/13W / 1400 mA - 4000 K	1302.5	80
131-0184	rectangular asymmetric Type II [R45]	LED-3/13W / 1400 mA - 3000 K	1123.1	80
131-0185	rectangular asymmetric Type II [R45]	LED-3/13W / 1400 mA - 4000 K	1174.2	80
131-9734	symmetric, medium beam up and down [M/M]	LED-2x3/26W / 1400mA - 3000 K	2224.9	80
131-9739	symmetric, medium beam up and down [M/M]	LED-2x3/26W / 1400mA - 4000 K	2326	80
131-9736	symmetric, narrow beam up and down [N/N]	LED-2x3/26W / 1400mA - 3000 K	2492.4	80
131-9741	symmetric, narrow beam up and down [N/N]	LED-2x3/26W / 1400mA - 4000 K	2605.7	80
131-9735	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/26W / 1400mA - 3000 K	2358.7	80
131-9740	symmetric, narrow beam up and medium beam down [N/M]	LED-2x3/26W / 1400mA - 4000 K	2465.9	80
131-9732	medium beam up and forward throw down [M/R45]	LED-2x3/26W / 1400mA - 3000 K	2235.7	80
131-9737	medium beam up and forward throw down [M/R45]	LED-2x3/26W / 1400mA - 4000 K	2337.3	80

Showing 1 to 50 of 87 entries.

Accessories

	Part-ID	Title	Specifications
	131-6000	QLS410 Surface Collar
