PIA240 LED

Back
Family Spec Sheet
410 mm 410 mm 250 mm 250 mm
560 mm 560 mm 330 mm 330 mm

IP66. Class I. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens, hinged. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Luminaire +15°/-30° tiltable. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK08
SchutzartIP66
AbdeckungPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter
Kabel
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
108-1649[S65] Type III MediumLED-18/54W / 1050 mA - 3000 K6202.280electronic gear32.00
108-1650[S65] Type III MediumLED-18/54W / 1050 mA - 4000 K6490.780electronic gear32.00
108-1759[S65] Type III MediumLED-24/72W / 1050 mA - 3000 K8269.680electronic gear32.00
108-1760[S65] Type III MediumLED-24/72W / 1050 mA - 4000 K8654.280electronic gear32.00
108-1653[R65] Type IV MediumLED-18/54W / 1050 mA - 3000 K6004.180electronic gear32.00
108-1654[R65] Type IV MediumLED-18/54W / 1050 mA - 4000 K6283.380electronic gear32.00
108-1761[R65] Type IV MediumLED-24/72W / 1050 mA - 3000 K8005.480electronic gear32.00
108-1762[R65] Type IV MediumLED-24/72W / 1050 mA - 4000 K8377.880electronic gear32.00
108-1655[A60] Type IV Very ShortLED-18/54W / 1050 mA - 3000 K5782.280electronic gear32.00
108-1763[A60] Type IV Very ShortLED-24/72W / 1050 mA - 3000 K7709.680electronic gear32.00
108-1764[A60] Type IV Very ShortLED-24/72W / 1050 mA - 4000 K8068.280electronic gear32.00
108-1656[A60] Type IV Very ShortLED-18/54W / 1050 mA - 4000 K6051.180electronic gear32.00
108-2541[S65] Type III MediumLED-18/54W / 1050 mA - 2700 K5913.780electronic gear32.00
108-2542[S65] Type III MediumLED-24/72W / 1050 mA - 2700 K788580electronic gear32.00
108-2543[A60] Type IV Very ShortLED-18/54W / 1050 mA - 2700 K5513.280electronic gear32.00
108-2544[A60] Type IV Very ShortLED-24/72W / 1050 mA - 2700 K735180electronic gear32.00
108-2545[R65] Type IV MediumLED-18/54W / 1050 mA - 2700 K5724.880electronic gear32.00
108-2546[R65] Type IV MediumLED-24/72W / 1050 mA - 2700 K7633.180electronic gear32.00
Showing 1 to 18 of 18 Entries
