RAIL66 system allows for slidable placement. IP66. Class I. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens, hinged. Including 1 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Advanced thermal management protects LEDs while optimizing lumens output. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Mount permits 355° rotation and 180° tilt. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

FLB141 LED #6 Asymmetric Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter
Cable1.3 ft of flexible cable
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Additional Information

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
161-5948[P65] Type II MediumLED-6/18W / 1050 mA - 3000 K1523.780
161-5950[P65] Type II MediumLED-6/18W / 1050 mA - 4000 K1594.680
161-5949[P65] Type II MediumLED-6/26W / 1400 mA - 3000 K1948.980
161-5951[P65] Type II MediumLED-6/26W / 1400 mA - 4000 K2037.580
161-5944[S70] Type II ShortLED-6/18W / 1050 mA - 3000 K1597.180
161-5946[S70] Type II ShortLED-6/18W / 1050 mA - 4000 K1671.380
161-5945[S70] Type II ShortLED-6/26W / 1400 mA - 3000 K2042.880
161-5947[S70] Type II ShortLED-6/26W / 1400 mA - 4000 K2135.680
161-5956[A60] Type IV Very ShortLED-6/18W / 1050 mA - 3000 K1468.780
161-5958[A60] Type IV Very ShortLED-6/18W / 1050 mA - 4000 K153780
161-5957[A60] Type IV Very ShortLED-6/26W / 1400 mA - 3000 K1878.680
161-5959[A60] Type IV Very ShortLED-6/26W / 1400 mA - 4000 K196480
161-5952[R65] Type IV MediumLED-6/18W / 1050 mA - 3000 K1457.180
161-5954[R65] Type IV MediumLED-6/18W / 1050 mA - 4000 K1524.980
161-5953[R65] Type IV MediumLED-6/26W / 1400 mA - 3000 K1863.780
161-5955[R65] Type IV MediumLED-6/26W / 1400 mA - 4000 K1948.580
Showing 1 to 16 of 16 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
161-9118Wire guard EG
