RGBW/RGBA Color Changer Profile Projector [FP] for framing applications, polygon shape.
Spherical and aspherical, double flat convex lens system. Aperture angle ranges from 14.6-22°.
IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland, second gland for through wiring on request. PMMA LED lens array. Integral driver, thermally separated. Factory-installed LED circuit board. RGBW/RGBA. DMX interface.
For the M20 cable gland for network- and DMX-connection, WE-EF recommends a multi-core cable for DMX and power, “Power PUR-SR 3x1,5 + DMX”.
Color Boost technology: With Color Boost the targeted and selective control of individual channels or colors means that a higher power of the LEDs can be accessed than in total when all colors are simultaneously operated. The light output is thus maximized by targeted control of individual channels/colors.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
Gehäuse
Marine-grade, die-cast aluminium alloy
Schrauben
PCS Polymer Coated Stainless Steel Hardware
Farben
Pending
Dichtung
Silicone CCG® Controlled Compression Gasket
Schlagfestigkeit
IP66
Schutzart
IK07
Abdeckung
Korrosionsschutz
5CE
Befestigung
Elektrik
LED Treiber
Integral EC electronic converter with DMX Interface
Kabel
Leistungsfaktor
> 0.9
Netz
Integral [ECG] electronic driver 120V-277V.
Überspannungsschutz
Weitere Eigenschaften
Lifetime
Ta=25°/40° L70B50 > 50000h
----
Lichtverteilung
Lichtstrom (lm)
Farbtemperatur (K)
CRI
Artikelnummer
Lichtverteilung
Lichtquelle
Bemessungslichtstrom
CRI
Vorschaltgerät
Gewicht (kg)
Open Data (txt)
Datenblatt
IES, LDT, ULD
139-2297_min
symmetric Framing-Projector [FP] - min aperture angle
LED-FT-24W - RGBW/4K
428.8
20/80
electronic gear
18.10
139-2329_min
symmetric Framing-Projector [FP] - min aperture angle
LED-FT-24W - RGBA
367.5
20
electronic gear
18.10
139-2297_max
symmetric Framing-Projector [FP] - max aperture angle
LED-FT-24W - RGBW/4K
667.8
20/80
electronic gear
18.10
139-2329_max
symmetric Framing-Projector [FP] - max aperture angle
