FLC200 | Frame Projector
FLC210 TW LED [FP] TUNABLE WHITE FRAMING PROJECTOR
Family Spec SheetTunable White Profile Projector [FP] for framing applications, polygon shape. Spherical and aspherical, double flat convex lens system. IP66, Class I. IK05. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through wiring on request. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory installed LED circuit board. Tunable White technology. DMX interface. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)
![FLC210 TW LED [FP] TUNABLE WHITE FRAMING PROJECTOR Schematics](https://api.we-ef.com/files/image/luminaire_families/features_image/MW_D_US_FLC210_LED_PP.png)
Colors
Material
Body: Marine-grade, die-cast aluminium alloy
Fasteners: PCS Polymer Coated Stainless Steel Hardware
Gasket: Silicone CCG® Controlled Compression Gasket
Impact Protection: IK05
Ingress Protection: IP66
Finish:
Corrosion Protection: 5CE
Mounting:
Electrical
Ballast / Driver: DMX (separate gearbox)
Cable: One cable gland, second gland for through-wiring on request
Power Factor: > 0.9
Power Supply:
Surge Protection:
Additional Information
Lifetime: Ta=25°/40° L70B50 > 50000h
:
:
