VFL500 series

VFL530 LED

Static White

Choose a variant:

Post-Top
Side-Entry

Choose a family:

VFL520 LED
L×W: 18.50"×8.27"
VFL530 LED
L×W: 18.50"×12.99"
VFL540 LED
L×W: 23.23"×12.99"
Home
Products
Street and Area Lighting
VFL530 LED
Family Spec Sheet Installation Instructions More Downloads

Pole or wall-mounted LED luminaire with integrated heat sinks. IP66. Class I or Class II. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. RFC® Reflection Free Contour main lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Spigot Ø 3”x5” optional available, must be indicated during order placement. Luminaire is factory-sealed and does not need to be opened during installation. Recommended mounting height 10-30 ft, depending on lamp type selected. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

VFL530 LED Schematics
Colors
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel hardware
GasketSilicone rubber gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Corrosion Protection5CE
MountingMaximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height
Electrical
Ballast / DriverIntegral EC electronic converter
Cable30 feet of flexible 18/5 cable
Power Factor> 0.9
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge ProtectionIn-line bracket 10kV Surge Protector
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
108-1123[S60] Type III ShortLED-12/12W / 350 mA - 3000 K1725.280 ULD
108-1124[S60] Type III ShortLED-12/12W / 350 mA - 4000 K1892.180 ULD
108-1126[S70] Type II ShortLED-12/12W / 350 mA - 3000 K1720.280 ULD
108-1127[S70] Type II ShortLED-12/12W / 350 mA - 4000 K1886.780 ULD
108-1129[A60] Type IV Very ShortLED-12/12W / 350 mA - 3000 K1626.180 ULD
108-1130[A60] Type IV Very ShortLED-12/12W / 350 mA - 4000 K1783.580 ULD
108-1132[S65] Type III MediumLED-12/12W / 350 mA - 3000 K1749.480 ULD
108-1133[S65] Type III MediumLED-12/12W / 350 mA - 4000 K1918.780 ULD
108-1135[R65] Type IV MediumLED-12/12W / 350 mA - 3000 K1671.980 ULD
108-1136[R65] Type IV MediumLED-12/12W / 350 mA - 4000 K1833.780 ULD
108-1138[S60] Type III ShortLED-12/24W / 700 mA - 3000 K3120.980 ULD
108-1139[S60] Type III ShortLED-12/24W / 700 mA - 4000 K3336.180 ULD
108-1141[S70] Type II ShortLED-12/24W / 700 mA - 3000 K3090.480 ULD
108-1142[S70] Type II ShortLED-12/24W / 700 mA - 4000 K3303.580 ULD
108-1144[A60] Type IV Very ShortLED-12/24W / 700 mA - 3000 K2887.480 ULD
108-1145[A60] Type IV Very ShortLED-12/24W / 700 mA - 4000 K3086.580 ULD
108-1147[S65] Type III MediumLED-12/24W / 700 mA - 3000 K315680 ULD
108-1148[S65] Type III MediumLED-12/24W / 700 mA - 4000 K3373.680 ULD
108-1150[R65] Type IV MediumLED-12/24W / 700 mA - 3000 K2927.280 ULD
108-1151[R65] Type IV MediumLED-12/24W / 700 mA - 4000 K3129.180 ULD
108-1153[S60] Type III ShortLED-24/24W / 350 mA - 3000 K3450.380 ULD
108-1154[S60] Type III ShortLED-24/24W / 350 mA - 4000 K3784.280 ULD
108-1156[S70] Type II ShortLED-24/24W / 350 mA - 3000 K3440.480 ULD
108-1157[S70] Type II ShortLED-24/24W / 350 mA - 4000 K3773.380 ULD
108-1159[A60] Type IV Very ShortLED-24/24W / 350 mA - 3000 K3252.280 ULD
108-1160[A60] Type IV Very ShortLED-24/24W / 350 mA - 4000 K3566.980 ULD
108-1162[S65] Type III MediumLED-24/24W / 350 mA - 3000 K3498.880 ULD
108-1163[S65] Type III MediumLED-24/24W / 350 mA - 4000 K3837.480 ULD
108-1165[R65] Type IV MediumLED-24/24W / 350 mA - 3000 K3343.880 ULD
108-1166[R65] Type IV MediumLED-24/24W / 350 mA - 4000 K3667.480 ULD
108-1168[S60] Type III ShortLED-24/48W / 700 mA - 3000 K6241.880 ULD
108-1169[S60] Type III ShortLED-24/48W / 700 mA - 4000 K6672.280 ULD
108-1171[S70] Type II ShortLED-24/48W / 700 mA - 3000 K6180.880 ULD
108-1172[S70] Type II ShortLED-24/48W / 700 mA - 4000 K6607.180 ULD
108-1174[A60] Type IV Very ShortLED-24/48W / 700 mA - 3000 K5774.880 ULD
108-1175[A60] Type IV Very ShortLED-24/48W / 700 mA - 4000 K617380 ULD
108-1177[S65] Type III MediumLED-24/48W / 700 mA - 3000 K631280 ULD
108-1178[S65] Type III MediumLED-24/48W / 700 mA - 4000 K6747.380 ULD
108-1180[R65] Type IV MediumLED-24/48W / 700 mA - 3000 K5854.580 ULD
108-1181[R65] Type IV MediumLED-24/48W / 700 mA - 4000 K6258.280 ULD
108-1552[P65] Type II MediumLED-12/12W / 350 mA - 3000 K1708.380 ULD
108-1553[P65] Type II MediumLED-12/12W / 350 mA - 4000 K1873.680 ULD
108-1554[P65] Type II MediumLED-12/24W / 700 mA - 3000 K3122.480 ULD
108-1555[P65] Type II MediumLED-12/24W / 700 mA - 4000 K3337.780 ULD
108-1556[P65] Type II MediumLED-24/24W / 350 mA - 3000 K3416.680 ULD
108-1557[P65] Type II MediumLED-24/24W / 350 mA - 4000 K3747.280 ULD
108-1558[P65] Type II MediumLED-24/48W / 700 mA - 3000 K6244.880 ULD
108-1559[P65] Type II MediumLED-24/48W / 700 mA - 4000 K6675.580 ULD
108-2040[A60] Type IV Very ShortLED-24/72W / 1050 mA - 3000 K8506.180 ULD
108-2041[A60] Type IV Very ShortLED-24/72W / 1050 mA - 4000 K8901.880 ULD
Showing 1 to 50 of 96 entries.
