CFT540 LED

Back
Standard Colours
Colour Changer
Family Spec Sheet
CFT530 CFT530 286 mm 286 mm 532 mm 532 mm
CFT540 CFT540 323 mm 323 mm 700 mm 700 mm

IP66. Class I. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. RFC® Reflection Free Contour main lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Recommended mounting height 10-20 ft, depending on wattage selected; brackets to be ordered separately. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine grade aluminum alloy.
SchraubenPCS Polymer Coated Stainless Steel hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK08
SchutzartIP66
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz5CE
BefestigungLuminaire requires a 2.99" diam x 3.94" long pole top tenon

Elektrik

LED TreiberIntegral EC electronic converter
Kabel30 feet of flexible 18/5 cable
Leistungsfaktor> 0.9
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIn-line bracket 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
105-0076[C50] Type V ShortLED-36/36W / 350 mA - 3000 K5266.280electronic gear28.22
105-0077[C50] Type V ShortLED-36/36W / 350 mA - 4000 K5775.980electronic gear28.22
105-0078[C50] Type V ShortLED-36/72W / 700 mA - 3000 K9376.780electronic gear28.22
105-0079[C50] Type V ShortLED-36/72W / 700 mA - 4000 K10023.380electronic gear28.22
105-0084rectangular [R]LED-36/72W / 700 mA - 3000 K9273.980electronic gear28.22
105-0085rectangular [R]LED-36/72W / 700 mA - 4000 K9913.580electronic gear28.22
105-0080[C50] Type V ShortLED-36/108W / 1050 mA - 3000 K14032.380electronic gear28.22
105-0081[C50] Type V ShortLED-36/108W / 1050 mA - 4000 K1468580electronic gear28.22
105-0086rectangular [R]LED-36/108W / 1050 mA - 3000 K13644.580electronic gear28.22
105-0087rectangular [R]LED-36/108W / 1050 mA - 4000 K14279.180electronic gear28.22
105-0241[C50] Type V ShortLED-36/36W / 350 mA - 2700 K4926.580electronic gear28.22
105-0242[C50] Type V ShortLED-36/72W / 700 mA - 2700 K873080electronic gear28.22
105-0243[C50] Type V ShortLED-36/108W / 1050 mA - 2700 K13379.780electronic gear28.22
105-0244rectangular [R]LED-36/36W / 350 mA - 2700 K4872.680electronic gear28.22
105-0245rectangular [R]LED-36/72W / 700 mA - 2700 K8634.380electronic gear28.22
105-0246rectangular [R]LED-36/108W / 1050 mA - 2700 K13009.880electronic gear28.22
Showing 1 to 16 of 16 Entries
