CFT530 LED

Back
Standard Colours
Colour Changer
Family Spec Sheet
CFT530 CFT530 286 mm 286 mm 532 mm 532 mm
CFT540 CFT540 323 mm 323 mm 700 mm 700 mm

IP66. Class I. IK08. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. RFC® Reflection Free Contour main lens. Integral driver in thermally separated compartment. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Recommended mounting height 10 – 13 ft, depending on wattage selected. Specify product with 7 Digit product code – Finish Color. (Other accessories, such as mounting, optical, and electrical, must be specified separately.). Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessories)

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK08
SchutzartIP66
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter
Kabel30 feet of flexible 18/5 cable
Leistungsfaktor> 0.9
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIn-line bracket 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
105-0092[C50] Type V ShortLED-24/24W / 350 mA - 3000 K3510.880electronic gear21.61
105-0093[C50] Type V ShortLED-24/24W / 350 mA - 4000 K3850.680electronic gear21.61
105-0094rectangular [R]LED-24/24W / 350 mA - 3000 K3472.480electronic gear21.61
105-0095rectangular [R]LED-24/24W / 350 mA - 4000 K3808.580electronic gear21.61
105-0096[C50] Type V ShortLED-24/48W / 700 mA - 3000 K6251.180electronic gear21.61
105-0097[C50] Type V ShortLED-24/48W / 700 mA - 4000 K6682.280electronic gear21.61
105-0098rectangular [R]LED-24/48W / 700 mA - 3000 K6182.680electronic gear21.61
105-0099rectangular [R]LED-24/48W / 700 mA - 4000 K660980electronic gear21.61
105-0237[C50] Type V ShortLED-24/24W / 350 mA - 2700 K3284.380electronic gear21.61
105-0238[C50] Type V ShortLED-24/48W / 700 mA - 2700 K582080electronic gear21.61
105-0239rectangular [R]LED-24/24W / 350 mA - 2700 K3248.480electronic gear21.61
105-0240rectangular [R]LED-24/48W / 700 mA - 2700 K5756.280electronic gear21.61
Showing 1 to 12 of 12 Entries
