BSP544 LED

Back
Family Spec Sheet
BSP534 BSP534 375 mm 375 mm 560 mm 560 mm
BSP544 BSP544 430 mm 430 mm 700 mm 700 mm

IP55. Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Recommended mounting height 10-20 ft, depending on lamp type selected; brackets to be ordered separately. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1) For DarkSky compliant configurations of this product, please find the spec sheet and DarkSky certificate in the library.

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK10
SchutzartIP55
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz5CE
BefestigungLuminaire requires a mounting bracket for mounting to wall or pole. Refer to mounting accessories for wall bracket and luminaire assembly brackets.

Elektrik

LED TreiberIntegral EC electronic converter
Kabel
Leistungsfaktor> 0.9
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
127-1302[S65] Type III MediumLED-24/48W / 700 mA - 3000 K5920.980electronic gear28.90
127-1303[S65] Type III MediumLED-24/48W / 700 mA - 4000 K6329.380electronic gear28.90
127-1304[S65] Type III MediumLED-36/72W / 700 mA - 3000 K8881.480electronic gear28.90
127-1305[S65] Type III MediumLED-36/72W / 700 mA - 4000 K9493.980electronic gear28.90
127-1306[R65] Type IV MediumLED-24/48W / 700 mA - 3000 K5398.980electronic gear28.90
127-1307[R65] Type IV MediumLED-24/48W / 700 mA - 4000 K5771.280electronic gear28.90
127-1308[R65] Type IV MediumLED-36/72W / 700 mA - 3000 K8098.380electronic gear28.90
127-1309[R65] Type IV MediumLED-36/72W / 700 mA - 4000 K8656.880electronic gear28.90
127-1433[S65] Type III MediumLED-24/48W / 700 mA - 2700 K5512.680electronic gear28.90
127-1434[S65] Type III MediumLED-36/72W / 700 mA - 2700 K8268.980electronic gear28.90
127-1435[R65] Type IV MediumLED-24/48W / 700 mA - 2700 K5026.580electronic gear28.90
127-1436[R65] Type IV MediumLED-36/72W / 700 mA - 2700 K7539.880electronic gear28.90
Showing 1 to 12 of 12 Entries
