ASP544 LED
Family Spec Sheet Installation Instructions More Downloads

IP55, Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. Integral driver in thermally separated compartment. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming comes standard with luminaire. Recommended mounting height 10 – 20 ft, depending on lamp type selected. Brackets to be ordered separately. Specify product with 7 Digit product code – Finish Color. (Other accessories, such as mounting, optical, and electrical, must be specified separately.) Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessories) For DarkSky compliant configurations of this product, please find the spec sheet and DarkSky certificate in the library.

ASP544 LED Schematics
Colors
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel hardware
GasketSilicone rubber gasket
Impact ProtectionIK10
Ingress ProtectionIP55
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Corrosion Protection5CE
MountingLuminaire requires a mounting bracket for mounting to wall or pole. Refer to mounting accessories for wall bracket and luminaire assembly brackets.
Electrical
Ballast / DriverIntegral EC electronic converter
Power Factor> 0.9
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge ProtectionIntegral 10kV Surge Protector
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Rated Lumen

Wattage

To
Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
127-1286[S65] Type III MediumLED-24/48W / 700 mA - 3000 K5920.980 ULD
127-1287[S65] Type III MediumLED-24/48W / 700 mA - 4000 K6329.380 ULD
127-1288[S65] Type III MediumLED-36/72W / 700 mA - 3000 K8881.480 ULD
127-1289[S65] Type III MediumLED-36/72W / 700 mA - 4000 K9493.980 ULD
127-1292[R65] Type IV MediumLED-36/72W / 700 mA - 3000 K8098.380 ULD
127-1293[R65] Type IV MediumLED-36/72W / 700 mA - 4000 K8656.880 ULD
127-1290[R65] Type IV MediumLED-24/48W / 700 mA - 3000 K5398.980 ULD
127-1291[R65] Type IV MediumLED-24/48W / 700 mA - 4000 K5771.280 ULD
127-1425[S65] Type III MediumLED-24/48W / 700 mA - 2700 K5512.680 ULD
127-1426[S65] Type III MediumLED-36/72W / 700 mA - 2700 K8268.980 ULD
127-1426[R65] Type IV MediumLED-24/48W / 700 mA - 2700 K5026.580 ULD
127-1428[R65] Type IV MediumLED-36/72W / 700 mA - 2700 K7539.880 ULD
127-1286-70[S65] Type III MediumLED-24/48W / 700 mA - 3000 K6737.670 ULD
