R2S. IP66, Class III. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. CCG® Controlled Compression Gasket. Non-reflective flat safety glass cover, hinged. Integral LED driver. The luminaire only has one input for the 24V DC supply voltage. Controls or sensors are not included and must be ordered separately depending on the solar system selected. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. The luminaire is factory-sealed and does not need to be opened during installation. Can be used as post top or side entry version. Specification at time of order is recommended.
Spigot Ø 76 x 100 mm. Spigot Ø 60 x 100 mm or 42 x 100 mm option available. Must be indicated during order placement.
Contact WE-EF direct or your local WE-EF sales representative for an individual solution designed to precisely meet your needs.
Photometric files (IES, LDT) for light distributions [A61] [P66] with Backlight Shield on request.
Eigenschaften
Material
Gehäuse
Marine-grade, die-cast aluminium alloy
Schrauben
PCS Polymer Coated Stainless Steel Hardware
Farben
Pending
Dichtung
CCG® Controlled Compression Gasket
Schlagfestigkeit
IK08
Schutzart
IP66
Abdeckung
Korrosionsschutz
5CE
Befestigung
Spigot rotatable for either post top or side entry version. Must be indicated during order placement.
