LTP400

Choose a variant:

1.500 mm

4.000 mm

Downloads

Family Spec Sheet Installation Instructions More Downloads

IP44, Class I. IK10. Marine-grade aluminium construction. 5CE superior corrosion protection including PCS hardware. Silicone rubber gaskets. Prismatic polycarbonate lenses, 3 x 120° offset. Service door with fused cable connecting box.

Colours

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

RAL8019 Dark Bronze

Material

Body	Marine-grade, all-aluminium construction
Fasteners	PCS Polymer Coated Stainless Steel hardware
Gasket	Silicone rubber gasket
Impact Protection	IK10
Ingress Protection	IP44
Finish	Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection	5CE

Electrical

Ballast / Driver	Integral EC electronic converter
Power Factor	> 0.9
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Additional Information

Lifetime	Ta=25°/40° L70B50 > 50000h
BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
116-0207	three sided light output	LED-FT-37W (3000K)	2546.5	80
116-0205	three sided light output	LED-FT-37W (4000K)	2656.2	80

Showing 1 to 2 of 2 Entries

Accessories

	Part-ID	Title	PDF	Open Data
	300-0456	Planted root ESD6
