ESC130 LED

ESC130 LED

IP67. Class I. IK07. Stainless steel construction inground section. Marine-grade, die-cast aluminum alloy hood with 30° angle avoids glare to passers-by and helps prevent accumulation of insects, leaves and debris on the lens. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Factory-sealed termination chamber complete with cable gland including spiral cable bending protection and 3 ft of flexible PVC-free cable. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Suitable for flush installation in concrete or earth. The optional installation blockout is recommended for mounting; to be ordered separately. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

ESC130 LED Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyStainless steel body. Marine grade high pressure die cast aluminum frame
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone rubber gasket
Impact ProtectionIK07
Ingress ProtectionIP67
FinishPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter
Cable3 feet of flexible 18/3 cable
Power Factor> 0.9
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection6/6 kV
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
Dimming0-10V available in request. Must be factory fitted.

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-3077symmetric, medium beam [M]LED-12/18W / 500 mA - 3000 K1755.180
185-3078symmetric, medium beam [M]LED-12/18W / 500 mA - 4000 K1877.580
185-3079symmetric, very narrow beam [VN]LED-12/18W / 500 mA - 3000 K1801.180
185-3080symmetric, very narrow beam [VN]LED-12/18W / 500 mA - 4000 K1926.880
185-3081symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/18W / 500 mA - 3000 K1894.380
185-3082symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/18W / 500 mA - 4000 K2026.480
185-3531symmetric, medium beam [M]LED-12/18W / 500 mA - 2700 K1632.680
185-3506symmetric, very narrow beam [VN]LED-12/18W / 500 mA - 2700 K1675.480
185-3532symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/18W / 500 mA - 2700 K1762.180
Showing 1 to 9 of 9 Entries
