DAS100

IP66, Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. Ceiling mount through canopy. Cable suspension 1.5 - 5 ft., to be specified at time at ordering. Integral driver, thermally separated. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming comes standard with luminaire. The luminaire is factory-sealed and does not need to be opened during installation. Optional 2200 K version available, to be specified at time of ordering. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Material

Body: Marine-grade, all aluminium construction

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting: Ceiling mount through canopy, drop guard through wire rope. Factory sealed till canopy. Cable suspension 0.5 m, ceiling mount through canopy. Longer cable suspension available on request

Electrical

Ballast / Driver: Integral EC electronic converter in thermally-separated compartment

Cable: Two cable entries on canopy for trough wiring

Power Factor: >0.9

Power Supply:

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
134-2207	symmetric, wide beam [W]	LED-12/24W / 700 mA - 3000 K	2558.9	80
134-2206	symmetric, wide beam [W]	LED-12/24W / 700 mA - 2700 K	2382.4	80
134-2208	symmetric, wide beam [W]	LED-12/24W / 700 mA - 4000 K	2735.4	80
134-2209	symmetric, medium beam [M]	LED-12/24W / 700 mA - 2700 K	2875.2	80
134-2210	symmetric, medium beam [M]	LED-12/24W / 700 mA - 3000 K	3088.2	80
134-2211	symmetric, medium beam [M]	LED-12/24W / 700 mA - 4000 K	3301.2	80
134-2212	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 2700 K	2880.3	80
134-2213	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 3000 K	3093.7	80
134-2214	symmetric, very narrow beam [VN]	LED-12/24W / 700 mA - 4000 K	3307	80
134-2215	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 2700 K	2947.4	80
134-2216	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 3000 K	3165.7	80
134-2217	symmetric, very narrow beam, 'sharp cut-off' [VNS]	LED-12/24W / 700 mA - 4000 K	3384	80

Showing 1 to 12 of 12 Entries
