DAC120 LED

DAC120 LED

Family Spec Sheet

IP66, Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. Integral driver, thermally separated. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming comes standard with luminaire. Optional 2200 K version available, to be specified at time of ordering. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)

DAC120 LED Schematics
Colors
Material

Body: Marine-grade, all aluminium construction

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting:

Electrical

Ballast / Driver: Integral EC electronic converter in thermally-separated compartment

Cable: Two cable entries

Power Factor: >0.9

Power Supply:

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

:

Light Distribution

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
134-2158symmetric, wide beam [W]LED-12/24W / 700 mA - 2700 K2382.480
134-2159symmetric, wide beam [W]LED-12/24W / 700 mA - 3000 K2558.980
134-2160symmetric, wide beam [W]LED-12/24W / 700 mA - 4000 K2735.480
134-2161symmetric, medium beam [M]LED-12/24W / 700 mA - 2700 K2875.280
134-2162symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K3088.280
134-2163symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3301.280
134-2164symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 2700 K2880.380
134-2165symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K3093.780
134-2166symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K330780
134-2167symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 2700 K2947.480
134-2168symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 3000 K3165.780
134-2169symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 4000 K338480
134-2161wallwash [A20]LED-12/24W / 700 mA - 2700 K1834.680
134-2162wallwash [A20]LED-12/24W / 700 mA - 3000 K1970.580
134-2163wallwash [A20]LED-12/24W / 700 mA - 4000 K2106.480
