IP66. Class I. IK10. Marine-grade, all aluminum construction. Pole section features anodized aluminum core. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens, UV-stabilized. CAD-optimized optics for superior illumination and glare control. Integral driver. Advanced thermal management protects LEDs while optimizing lumens output. Luminaire is factory-sealed and does not need to be opened during installation. Suitable for areas prone to flooding. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
RAL8019 Dark Bronze
Powdercoat finish available in 35 different colours
RAL9016 Traffic white
Material
| Body | Marine-grade, all-aluminium construction. Pole section features anodised aluminium core |
| Fasteners | PCS hardware |
| Gasket | Silicone CCG® Controlled Compression Gasket |
| Impact Protection | IK10 |
| Ingress Protection | IP66 |
| Finish | |
| Corrosion Protection | 5CE |
| Mounting | FS Factory-sealed luminaire does not need to be opened during installation |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Cable | |
| Power Factor | > 0.9 |
| Power Supply | Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order. |
| Surge Protection | 10/10kV |
Additional Information
| Ta=25⁰ L70B50>50000h | |
- - - -
