IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Includes 1 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
Gehäuse
Marine-grade die-cast aluminum alloy
Schrauben
PCS Polymer Coated Stainless Steel hardware
Farben
Pending
Dichtung
Silicone rubber gasket
Schlagfestigkeit
IK07
Schutzart
IP66
Abdeckung
Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Korrosionsschutz
5CE
Befestigung
Mounting clamp for installation to RAIL66 mounting system. Refer to mounting accessories for complete range of RAIL66 mounting systems
Elektrik
LED Treiber
Integral EC electronic converter in thermally-separated compartment
Kabel
1 ft of flexible cable
Leistungsfaktor
Netz
Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz
Weitere Eigenschaften
Lifetime
Ta=25°/40° L90B10 > 90000h
----
Lichtverteilung
Lichtstrom (lm)
Farbtemperatur (K)
Artikelnummer
Lichtverteilung
Lichtquelle
Bemessungslichtstrom
CRI
Vorschaltgerät
Gewicht (kg)
Open Data (txt)
Datenblatt
IES, LDT, ULD
146-0411
symmetric, medium beam [M]
LED-12/24W / 700 mA - 3000 K
2998.6
80
electronic gear
6.80
146-0412
symmetric, medium beam [M]
LED-12/24W / 700 mA - 4000 K
3205.4
80
electronic gear
6.80
146-0414
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-12/24W / 700 mA - 3000 K
3077.9
80
electronic gear
6.80
146-0414
linear spread, very narrow beam, 'sharp cut-off'
LED-12/24W / 700 mA - 3000 K
2865.9
80
electronic gear
6.80
146-0415
symmetric, very narrow beam, 'sharp cut-off' [VNS]
LED-12/24W / 700 mA - 4000 K
3290.2
80
electronic gear
6.80
146-0415
linear spread, very narrow beam, 'sharp cut-off'
LED-12/24W / 700 mA - 4000 K
3063.5
80
electronic gear
6.80
146-0530
symmetric, wide beam [W]
LED-12/24W / 700 mA - 3000 K
2709.2
80
electronic gear
6.80
146-0531
symmetric, wide beam [W]
LED-12/24W / 700 mA - 4000 K
2896
80
electronic gear
6.80
146-0533
symmetric, very narrow beam [VN]
LED-12/24W / 700 mA - 3000 K
2883.7
80
electronic gear
6.80
146-0533
linear spread, very narrow beam [VN]
LED-12/24W / 700 mA - 3000 K
2744.2
80
electronic gear
6.80
146-0534
symmetric, very narrow beam [VN]
LED-12/24W / 700 mA - 4000 K
3082.5
80
electronic gear
6.80
146-0534
linear spread, very narrow beam [VN]
LED-12/24W / 700 mA - 4000 K
2933.4
80
electronic gear
6.80
146-0412
wallwash [A20]
LED-12/24W / 700 mA - 4000 K
2571.5
80
electronic gear
6.80
146-0411
wallwash [A20]
LED-12/24W / 700 mA - 3000 K
2405.6
80
electronic gear
6.80
146-0980
symmetric, wide beam [W]
LED-12/24W / 700 mA - 2700 K
2522.3
80
electronic gear
6.80
146-0981
symmetric, medium beam [M]
LED-12/24W / 700 mA - 2700 K
2791.8
80
electronic gear
6.80
146-0982
symmetric, very narrow beam [VN]
LED-12/24W / 700 mA - 2700 K
2684.8
80
electronic gear
6.80
146-0983
symmetric, very narrow beam, 'sharp cut-off' [VNS]
