DOC200 series
DOC220-FT LED
IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Safety glass lens, hinged. Frame with safety catch. Two cable entries. Intergal ECG control gear in thermally separated compartment. Darklight anodised aluminium reflector, PMMA-Diffusor-Lens for glare control and soft wide beam distribution. Factory-installed LED circuit board. A pre-installation blockout, proud or flush, is available and recommended for mounting in concrete ceilings. To be ordered separately.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | Powdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Standard - optional DALI version available |
| Cable | Two cable entries |
| Power Supply | 220-240V / 50-60 Hz |
| Surge Protection | 6/6 kV |
Additional Information
| Lifetime | Ta=25° L70B50 > 50000h |
| Energy efficiency class | D (Light source) |
- - - -
Accessories
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
