SVL100+SVL200 series
SVL134 LED Shallow Depth
IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry. Second cable entry for through wiring available on request.
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Cable | One cable entry. Second cable entry for through wiring available on request. |
| Power Supply | 220-240V / 50-60 Hz |
Additional Information
- - - -
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
