STO100+STO200 series

STO134 LED Reduced Depth - Stainless Steel

Choose a variant:

Choose a family:

L270×W65×D75 mm | STO134 LED Reduced Depth - Stainless Steel L270×W65×D50 mm | STO134 LED Shallow Depth - Stainless Steel L270×W65×D120 mm | STO134 LED Stainless Steel L425×W135×D100 mm | STO279 LED Stainless steel

Home

Products

Recessed Wall Luminaires

STO134 LED Reduced Depth - Stainless Steel

Family Spec Sheet Installation Instructions More Downloads

IP66. IK07. Marine-grade, die-cast aluminium alloy, with polished stainless steel frame. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry.

STO134 LED Reduced Depth - Stainless Steel Schematics

Colours

Stainless Steel

Material

Body	Marine-grade, die-cast aluminium alloy with polished stainless steel frame
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone rubber gasket
Impact Protection	IK07
Ingress Protection	IP66
Corrosion Protection	5CE

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	One cable entry
Power Supply	220-240V / 50-60 Hz

Additional Information

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
190-9044	diffused distribution	LED-5W / 250 mA - 3000 K	78.6	80
190-9048	diffused distribution	LED-5W / 250 mA - 4000 K	81.7	80
190-9052	diffused distribution	LED-5W / 250 mA - 2700 K	75.4	80

Showing 1 to 3 of 3 entries.

Item	Download
Product Images
Photometrics
Installation Instructions
