STO100+STO200 series

STO134 LED Shallow Depth

Choose a variant:

Choose a family:

L270×W65×D120 mm | STO134 LED L270×W65×D75 mm | STO134 LED Reduced Depth L270×W65×D50 mm | STO134 LED Shallow Depth L425×W135×D100 mm | STO279 LED

Home

Products

Recessed Wall Luminaires

STO134 LED Shallow Depth

Family Spec Sheet Installation Instructions More Downloads

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry. Second cable entry for through wiring available on request.

Colours

RAL9004 Signal black

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone rubber gasket
Impact Protection	IK07
Ingress Protection	IP66
Corrosion Protection	5CE

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	One cable entry. Second cable entry for through wiring available on request.
Power Supply	220-240V / 50-60 Hz

Additional Information

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
190-9001	diffused distribution	LED-5W / 250 mA - 3000 K	78.6	80
190-9055	diffused distribution	LED-5W / 250 mA - 4000 K	81.7	80
190-9060	diffused distribution	LED-5W / 250 mA - 2700 K	75.4	80

Showing 1 to 3 of 3 entries.
