IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable.

Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry. Second cable entry for through wiring available on request.

STL100+STL200 series

STL134 LED Shallow Depth

Static White

Choose a family:

STL134 LED

Depth: 120 mm
L×W: 270×65 mm

STL134 LED Reduced Depth

Depth: 75 mm
L×W: 270×65 mm

STL134 LED Shallow Depth

Depth: 50 mm
L×W: 270×65 mm

Home

Products

Recessed Wall Luminaires

STL134 LED Shallow Depth

Family Spec Sheet More Downloads

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry. Second cable entry for through wiring available on request.

Colours

RAL9004 Signal black

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

Material

Impact Protection	IK07
Ingress Protection	IP66

Electrical

Cable	One cable entry. Second cable entry for through wiring available on request.
Power Supply	220-240V / 50-60 Hz

Additional Information

	Part-ID	Light Distribution	Light Source	Rated Lumen	CRI	Specifications	Photometrics
Searching...

Item	Download

STL134 LED Shallow Depth
