STI100+STI200 Série
STI134 LED Shallow Depth
IP66. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry. Second cable entry for through wiring available on request.
Couleurs
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Description du matériel
| Corps | Marine-grade, die-cast aluminium alloy |
| Visserie | PCS hardware |
| Joint | Silicone rubber gasket |
| IK | IK10 |
| IP | IP66 |
| Protection contre la corrosion | 5CE |
Description électrique
| Driver | Integral EC electronic converter |
| Câble | One cable entry. Second cable entry for through wiring available on request. |
| Alimentation électrique | 220-240V / 50-60 Hz |
Informations complémentaires
- - - -
| Item | Download |
|---|---|
| Images du produit | |
| Photométrie | |
| Instructions d'installation |
