ESC300 series
ESC330-FS LED
IP67. IK07. Stainless steel inground section. Die-cast hood made from marine-grade aluminium alloy. Construction helps to prevent accumulation of insects, leaves and debris on lens and restricts glare to passers-by. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Stainless steel inground section. Die-cast hood made from marine-grade aluminium alloy |
| Fasteners | PCS hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP67 |
| Finish | Powdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016 |
| Corrosion Protection | 5CE |
| Mounting | Luminaire installation blockout and sealable junction box included in supply |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Cable | Complete with cable gland and 0.5 m of flexible PVC-free cable |
Additional Information
- - - -
Accessories
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
