XRX300 series
XRX324 LED
IP55, Class I. IK10. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Polycarbonate prismatic lens. Silicone rubber gaskets. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output.
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade, all-aluminium construction |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone rubber gaskets |
| Impact Protection | IK10 |
| Ingress Protection | IP55 |
| Finish | Powdercoat finish in Classic Silver, black RAL 9004, grey aluminium RAL 9007 or white RAL 9016 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Integral EC electronic converter in thermally-separated compartment |
| Power Supply | 220-240V / 50-60 Hz |
Additional Information
| Lifetime | Ta=25° L80B10 > 54000h |
| BUG Rating | Please see individual Spec Sheets for classification of Backlight, Uplight and Glare |
- - - -
