GRY200 series

GRY224 LED

Static White

Choose a family:

H700 mm | GRY224 LED H1000 mm | GRY234 LED
Home
Products
Bollards and Pathway Luminaires
GRY224 LED
Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK10. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Polycarbonate lens. Silicone rubber gaskets. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output.

GRY224 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS hardware
GasketSilicone rubber gaskets
Impact ProtectionIK10
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
MountingPlanted root is available on request
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
114-9169360° symmetric distribution, shieldedLED-18/6W / 250 mA - 3000 K19780
114-9170360° symmetric distribution, shieldedLED-18/6W / 250 mA - 4000 K189.180
Showing 1 to 2 of 2 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
300-0461-APPlanted root ESV4
