OLV

220 mm

300 mm

12 – 18W 12 – 24W

Home

Products

Surface Mounted Wall Luminaires

OLV334 LED

Family Spec Sheet

IP65. IK08; IK10 on request with polycarbonate lens. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Advanced thermal management protects LEDs while optimizing lumens output. Luminaire can be mounted for up or down lighting. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Luminaire body and lens frame constructed in die cast aluminum.
Fasteners	PCS polymer coated stainless steel
Gasket	Silicone rubber gasket
Impact Protection	IK07
Ingress Protection	IP65
Finish	Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection	5CE
Mounting	Suitable for installation over a standard 4” recessed junction box. Luminaire can be mounted as an uplight, or downlight.

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Two cable entries
Power Factor
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
132-0526	[S70] Type II Short	LED-12/12W / 350 mA - 3000 K	1549.2	80
132-0527	[S70] Type II Short	LED-12/12W / 350 mA - 4000 K	1699.2	80
132-0528	[R65] Type IV Medium	LED-12/12W / 350 mA - 3000 K	1394.4	80
132-0529	[R65] Type IV Medium	LED-12/12W / 350 mA - 4000 K	1529.4	80
132-0530	[A60] Type IV Very Short	LED-12/12W / 350 mA - 3000 K	1476.3	80
132-0531	[A60] Type IV Very Short	LED-12/12W / 350 mA - 4000 K	1619.1	80
132-0536	[S70] Type II Short	LED-12/24W / 700 mA - 3000 K	2760.6	80
132-0537	[S70] Type II Short	LED-12/24W / 700 mA - 4000 K	2951	80
132-0538	[R65] Type IV Medium	LED-12/24W / 700 mA - 3000 K	2484.7	80
132-0539	[R65] Type IV Medium	LED-12/24W / 700 mA - 4000 K	2656.1	80
132-0540	[A60] Type IV Very Short	LED-12/24W / 700 mA - 3000 K	2630.6	80
132-0541	[A60] Type IV Very Short	LED-12/24W / 700 mA - 4000 K	2812	80
132-0637	[S70] Type II Short	LED-12/12W / 350 mA - 2700 K	1449.3	80
132-0638	[S70] Type II Short	LED-12/24W / 700 mA - 2700 K	2570.2	80
132-0639	[R65] Type IV Medium	LED-12/12W / 350 mA - 2700 K	1304.5	80
132-0640	[R65] Type IV Medium	LED-12/24W / 700 mA - 2700 K	2313.3	80
132-0641	[A60] Type IV Very Short	LED-12/12W / 350 mA - 2700 K	1381	80
132-0642	[A60] Type IV Very Short	LED-12/24W / 700 mA - 2700 K	2449.2	80
