DLO239 LED
IP55. Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. Integral driver. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Suitable for installation on ceiling or wall over 4" recessed junction box.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
| Gehäuse | Luminaire body and lens frame constructed in die cast aluminum. |
| Schrauben | PCS polymer coated stainless steel |
| Farben | Pending |
| Dichtung | Silicone rubber gasket |
| Schlagfestigkeit | IK10 |
| Schutzart | IP55 |
| Abdeckung | Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019. |
| Korrosionsschutz | 5CE |
| Befestigung | Suitable for installation on ceiling or wall over 4" recessed junciton box. |
Elektrik
| LED Treiber | Integral EC electronic converter |
| Kabel | Two cable entries |
| Leistungsfaktor | |
| Netz | Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order. |
| Überspannungsschutz |
Weitere Eigenschaften
| Lifetime | Ta=25°/40° L70B50 > 50000h |
- - - -
Lichtstrom (lm)
Farbtemperatur (K)
Showing 1 to 3 of 3 Entries
