DLG200 series
DLG229 LED
Choose a family:
ADA (American Disabilities Act) Compliant. IP55. Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. Integral driver. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Suitable for installation on ceiling or wall over 4" recessed junction box. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)
Colors
RAL9004 Black
RAL9016 White
RAL8019 Dark Bronze
RAL9007 Grey Metallic
Material
| Body | Luminaire body and lens frame constructed in die cast aluminum. |
| Lens | Opal polycarbonate lens. |
| Fasteners | PCS polymer coated stainless steel |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK10 |
| Ingress Protection | IP55 |
| Finish | Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019. |
| Corrosion Protection | 5CE |
| Mounting | Suitable for installation on ceiling or wall over 4" recessed junciton box. |
Electrical
| Ballast / Driver | Opal polycarbonate lens. |
| Cable | Two cable entries |
| Power Supply | Integral [ECG] LED driver in 120 or 277 volt. Specify voltage. |
Additional Information
| Diameter (inches) | 10.31 |
- - - -
