STP254 LED
Low glare steplight.
ADA (American Disabilities Act) Compliant.
IP55. Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. Two cable entries. Integral driver. Factory-installed LED circuit board. 0-10V Dimming standard.
A pre-installation blockout is available and recommended for mounting in concrete walls; to be ordered separately.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately.
Example: XXX-XXXX-9004 (Black)
+ XXX-XXXX (Accessory 1)
Eigenschaften
Material
| Gehäuse | Luminaire body and lens frame constructed in die cast aluminum. |
| Schrauben | PCS polymer coated stainless steel |
| Farben | Pending |
| Dichtung | Silicone rubber gasket |
| Schlagfestigkeit | IK10 |
| Schutzart | IP55 |
| Abdeckung | Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019. |
| Korrosionsschutz | 5CE |
| Befestigung | Suitable for installation in cavity wall construction or concrete pour construction using optional installation blockout. |
Elektrik
| LED Treiber | Integral EC electronic converter |
| Kabel | Suitable for through wiring. |
| Leistungsfaktor | |
| Netz | Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order. |
| Überspannungsschutz |
Weitere Eigenschaften
| Lifetime | Ta=25°/40° L80B10 > 54000h |
- - - -
Lichtstrom (lm)
Farbtemperatur (K)
