IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Including 1 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

FLC141 LED RAIL66 Schematics
Colors
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
BodyMarine-grade die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
FinishPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Corrosion Protection5CE
MountingMounting clamp for installation to RAIL66 mounting system. Refer to mounting accessories for complete range of RAIL66 mounting systems
Electrical
Ballast / DriverIntegral driver in thermally-separated compartment
Cable1 ft of flexible cable
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
146-7058symmetric, medium beam [M]LED-24/48W / 700 mA - 3000 K6047.280 ULD
146-7059symmetric, medium beam [M]LED-24/48W / 700 mA - 4000 K6464.280 ULD
146-7060symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 3000 K6442.780 ULD
146-7061symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 4000 K688780 ULD
146-7070symmetric, wide beam [W]LED-24/48W / 700 mA - 3000 K5388.580 ULD
146-7071symmetric, wide beam [W]LED-24/48W / 700 mA - 4000 K5760.180 ULD
146-7072symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 3000 K5986.180 ULD
146-7073symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 4000 K6398.980 ULD
146-7072linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 3000 K5545.280 ULD
146-7073linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 4000 K5927.680 ULD
146-7060linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 3000 K6104.980 ULD
146-7061linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 4000 K652680 ULD
146-7059wallwash [A20]LED-24/48W / 700 mA - 4000 K5186.680 ULD
146-7058wallwash [A20]LED-24/48W / 700 mA - 3000 K4851.980 ULD
146-0984symmetric, wide beam [W]LED-24/48W / 700 mA - 2700 K5016.980 ULD
146-0985symmetric, medium beam [M]LED-24/48W / 700 mA - 2700 K5630.180 ULD
146-0986symmetric, very narrow beam [VN]LED-24/48W / 700 mA - 2700 K5573.380 ULD
146-0987symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-24/48W / 700 mA - 2700 K5998.480 ULD
146-0985wallwash [A20]LED-24/48W / 700 mA - 2700 K4517.380
146-0986linear spread, very narrow beam [VN]LED-24/48W / 700 mA - 2700 K5162.880
146-0987linear spread, very narrow beam, 'sharp cut-off'LED-24/48W / 700 mA - 2700 K5683.980
Showing 1 to 21 of 21 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
146-0229Glare shield ES
ItemDownload
Product Images
Photometrics
Installation Instructions
