FLD100 series
FLD111 LED
Choose a family:
L3.74"×W3.74" | FLD111 LEDIP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
RAL8019 Dark Bronze
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS polymer coated stainless steel |
| Gasket | Silicone rubber gaskets |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Power Supply | 120-277V / 50-60 Hz |
Additional Information
| Lifetime | LED >60,000 h Ta 25°(L70/B10) Control gear >50,000 h Ta 25° |
- - - -
Accessories
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
