EFC100

IP67. Class I. IK09. Stainless steel construction inground section. Marine-grade, die-cast aluminum alloy dome. 5CE superior corrosion protection including PCS hardware. Semi-recessed, directional LED marker light with controlled single- or double-sided distribution. Silicone CCG® Controlled Compression Gasket. Luminaire can be driven over at low speeds only; it is not designed for normal traffic conditions, and can be damaged under such conditions as braking, accelerating, or turning. Factory-sealed termination chamber complete with cable gland and 4 ft of flexible PVC-free cable. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. 'No tool' removable gear/lens tray. Suitable for flush installation in concrete or earth. Luminaire requires installation blockout which is included in supply; blockout is designed for installation in concrete. IP68 in-line connector facilitates easy removal for off-site lamp replacement. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

EFC120 LED Schematics
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
RAL8019 Dark Bronze
Powdercoat finish available in 35 different colours
Material
BodyBody constructed from deep drawn stainless steel. Die cast aluminum dome and outer housing.
FastenersPCS polymer coated stainless steel
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK09
Ingress ProtectionIP67
FinishPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection5CE
MountingSuitable for installation in poured concrete applications only.
Electrical
Ballast / DriverIntegral driver
Cable4 ft of flexible cable
Power Factor> 0.9
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h
InstallationSuitable for installation in poured concrete applications only. On-site opening of luminaire not required. Concealed bayonet action locking device for access to lamp compartment. Proper drainage and foundation support must be provided under luminaire.

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-2526controlled beam, one-sidedLED-6/6W / 350 mA - 3000 K49780
185-2559controlled beam, two-sidedLED-2x6/12W / 350 mA - 3000K992.480
185-2560controlled beam, one-sidedLED-6/6W / 350 mA - 4000 K545.180
185-2768controlled beam, two-sidedLED-2x6/12W / 350 mA - 4000K1088.480
185-3047controlled beam, one-sidedLED-6/6W / 350 mA - 2700 K46580
185-3530controlled beam, two-sidedLED-2x6/12W / 350 mA - 2700 K928.380
Showing 1 to 6 of 6 Entries
