X-LINE NANO Fixe
Family Spec Sheet Installation Instructions More Downloads

IP66, Classe I. IK08. Profil aluminium anodisé incolore. PMMA clair. Joint silicone. Fixation sur deux équerres en aluminium anodisé. Visserie inox avec traitement anti couple galvanique Delta Seal®. Visière en option en aluminium brut, RAL à déterminer à la commande. Optique : 50x15°, 2x30°. Mini réglette à LED monochrome pour l'éclairage extérieur. NE PAS ENCASTRER.

X-LINE NANO Fixe Schematics
Colours
tous les RAL disponibles
Material
BodyProfil aluminium anodisé incolore. PMMA clair.
FastenersVisserie imperdable inox avec traitement anti couple galvanique Delta Seal®.
GasketJoint silicone
Impact ProtectionIK08
Ingress ProtectionIP66
Corrosion ProtectionEnrobage en résine semi-rigide polyuréthane qui absorbe les dilatations thermiques, diélectrique, étanche, sans solvant et sans halogène.
Electrical
Ballast / DriverFixe ou pilotable
CableVersion fixe : câble 2x0,5mm² : noir- et rouge+. Longueur : 150cm._BR_Version pilotable : câble noir numéroté 3x0,5mm². 1 (V-), 2 (V+), 3 dimming. Longueur : 150cm.
Power Factor> 0.9
Power SupplyAlimentation 24V DC + parasurtenseur 10 kA / 5 kA
Surge Protection10 kV / 5kA
Additional Information
Durée de vieTa=30° L80 B10 > 60 000 heures
GarantieGarantie 5ans : sur module LED et driver (voir les conditions FLUX).

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
819-0005symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - 2700K188.670
819-0010symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - 2700K377.270
819-0015symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - 2700K565.870
819-0020symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - 2700K754.470
819-0025symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - 2700K94370
819-0030symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - 3000K188.670
819-0055symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - 4000K198.470
819-0080symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - 6500K211.970
819-0105symmetric linear, asymmetric beam [50x15°]LED-FX-4/9W / 24V - ROUGE93.50
819-0130symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - VERT200.10
819-0155symmetric linear, asymmetric beam [50x15°]LED-FX-4/3W / 24V - BLEU R.22.60
819-0180symmetric linear, asymmetric beam [50x15°]LED-FX-4/9W / 24V - AMBRE86.30
819-0035symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - 3000K377.270
819-0040symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - 3000K565.870
819-0045symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - 3000K754.470
819-0050symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - 3000K94370
819-0060symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - 4000K396.970
819-0065symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - 4000K634.770
819-0070symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - 4000K793.870
819-0075symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - 4000K992.270
819-0085symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - 6500K423.870
819-0090symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - 6500K635.770
819-0095symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - 6500K847.670
819-0100symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - 6500K1059.470
819-0110symmetric linear, asymmetric beam [50x15°]LED-FX-8/18W / 24V - ROUGE1870
819-0115symmetric linear, asymmetric beam [50x15°]LED-FX-12/27W / 24V - ROUGE280.40
819-0120symmetric linear, asymmetric beam [50x15°]LED-FX-16/9W / 24V - ROUGE373.90
819-0125symmetric linear, asymmetric beam [50x15°]LED-FX-20/45W / 24V - ROUGE467.40
819-0135symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - VERT400.20
819-0140symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - VERT600.20
819-0145symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - VERT800.30
819-0150symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - VERT1000.40
819-0160symmetric linear, asymmetric beam [50x15°]LED-FX-8/6W / 24V - BLEU R.45.30
819-0165symmetric linear, asymmetric beam [50x15°]LED-FX-12/9W / 24V - BLEU R.67.90
819-0170symmetric linear, asymmetric beam [50x15°]LED-FX-16/12W / 24V - BLEU R.90.50
819-0175symmetric linear, asymmetric beam [50x15°]LED-FX-20/15W / 24V - BLEU R.113.20
819-0185symmetric linear, asymmetric beam [50x15°]LED-FX-8/18W / 24V - AMBRE172.50
819-0190symmetric linear, asymmetric beam [50x15°]LED-FX-12/26W / 24V - AMBRE258.80
819-0195symmetric linear, asymmetric beam [50x15°]LED-FX-16/35W / 24V - AMBRE345.10
819-0200symmetric linear, asymmetric beam [50x15°]LED-FX-20/44W / 24V - AMBRE431.30
819-0505symmetric linear, wide beam [2x30°]LED-FX-4/3W / 24V - 2700K210.270
819-0510symmetric linear, wide beam [2x30°]LED-FX-8/6W / 24V - 2700K420.470
819-0515symmetric linear, wide beam [2x30°]LED-FX-12/9W / 24V - 2700K630.770
819-0520symmetric linear, wide beam [2x30°]LED-FX-16/12W / 24V - 2700K840.970
819-0525symmetric linear, wide beam [2x30°]LED-FX-20/15W / 24V - 2700K1051.170
819-0530symmetric linear, wide beam [2x30°]LED-FX-4/3W / 24V - 3000K210.270
819-0535symmetric linear, wide beam [2x30°]LED-FX-8/6W / 24V - 3000K420.470
819-0540symmetric linear, wide beam [2x30°]LED-FX-12/9W / 24V - 3000K630.770
819-0545symmetric linear, wide beam [2x30°]LED-FX-16/12W / 24V - 3000K840.970
819-0550symmetric linear, wide beam [2x30°]LED-FX-20/15W / 24V - 3000K1051.170
